MS16997-11 Socket Head Cap Screw

Product Series
MS
ECCN
EAR99
Schedule
7318.15.2091
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Flat chamfer
Material
Steel
Surface Treatment
Qq-p-416 type 2 cl 3 federal specification single treatment response
Thread Class
3a
Fastener Length
Between 0.469 inches and 0.500 inches
Hardness Rating
36.0 rockwell c and 45.0 rockwell c
Head Height
Between 0.108 inches and 0.112 inches
Internal Drive Style
Hexagon
Min. Tensile Strength (psi)
160000 pounds per square inch
Minimum Yield Strength
130000 pounds per square inch
Nondefinitive Specification/std Data
6 type
Thread Diameter
0.112 inches
Thread Direction
Right-hand
Thread Length
Between 0.419 inches and 0.500 inches
Thread Qty Per Inch (tpi)
40
Thread Series Designator
Unc (coarse thread)
Width Across Flats
Between 0.093 inches and 0.095 inches
Head Diameter
Between 0.176 inches and 0.183 inches
