MS172239 Plain Hexagon Nut

Product Series: MS
ECCN: EAR99
Schedule: 7318.16.0085

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote

Material

Steel

Thread Series

Uns

Thread Size

0.664 inches

Countersink Angle: 88.0 degrees first end and 92.0 degrees first end
Drive Point Depth: Between 0.0545 inches and 0.0645 inches
Drive Point Quantity: 8
Drive Point Width: 0.125 inches
Hardness Rating: Between 26.0 rockwell c and 32.0 rockwell c
Material Specification: Ams 6381 assn standard all material responses or ams 6382 assn standard all material responses
Nut Diameter: Between 1.047 inches and 1.067 inches
Nut Style: Round
Nut Thickness: 0.219 inches
Thread Direction: Right-hand
Thread Pitch Diameters: +0.6437/+0.6467 inches
Thread Qty Per Inch (tpi): 32
