MS17825-3 Self-Locking Slotted Hexagon Nut
MS17825-3 Self-Locking Slotted Hexagon Nut (2)
MS17825-3 Self-Locking Slotted Hexagon Nut (3)
MS17825-3 Self-Locking Slotted Hexagon Nut (4)
MS17825-3 Self-Locking Slotted Hexagon Nut
MS17825-3 Self-Locking Slotted Hexagon Nut (2)
MS17825-3 Self-Locking Slotted Hexagon Nut (3)
MS17825-3 Self-Locking Slotted Hexagon Nut (4)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS17825-3 Self-Locking Slotted Hexagon Nut

Product Series
MS
ECCN
EAR99
Schedule
7318.16.0085
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Steel nut
Surface Treatment
Class 2 federal specification single treatment response except insert type 2 qq-p-416
Thread Class
3b
Thread Series
Unjf (fine thread with external controlled root radius)
Thread Size
0.190 inches
Locking Feature
Prevailing torque with nonmetallic insert
Nut Height
Between 0.235 inches and 0.265 inches
Nut Style
hexagon slotted
Surface Type
Washer faced
Tempurature Rating
250 degrees fahrenheit
Thread Direction
Right-hand
Thread Qty Per Inch (tpi)
32
Width Across Flats
Between 0.367 inches and 0.376 inches
