MS17825-4 Self-Locking Slotted Hexagon Nut

Product Series
MS
ECCN
EAR99
Schedule
7318.16.0085
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Steel nut
Surface Treatment
Class 2 federal specification single treatment response except insert type 2 qq-p-416
Thread Class
3b
Thread Series
Unjf (fine thread with external controlled root radius)
Thread Size
0.25 inches
Bearing Surface Type
Washer faced
Locking Feature
Prevailing torque with nonmetallic insert
Nut Height
Between 0.266 inches and 0.296 inches
Nut Style
hexagon slotted
Tempurature Rating
250 degrees fahrenheit
Thread Direction
Right-hand
Thread Qty Per Inch (tpi)
28
Width Across Flats
Between 0.430 inches and 0.439 inches
