MS20005-10 Internal Wrenching Bolt

Product Series: MS
ECCN: EAR99
Schedule: 7318.15.8085

Price per Unit $6.25

Units per Pack 10

Price per Pack $62.50

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:

Total Packs 1

Total Price $62.50

Add item to quote

Head Style

Bevel-conical

Material

Steel

Surface Treatment

Qq-p-416 ty2 cl2 federal specification single treatment response

Thread Class

3a

Fastener Length: Between 1.173 inches and 1.203 inches
Head Height: 0.312 inches
Internal Drive Style: Hexagon
Thread Diameter: 0.312 inches
Thread Direction: Right-hand
Thread Length: 0.537 inches
Thread Qty Per Inch (tpi): 24
Thread Series Designator: Unjf (fine thread with external controlled root radius)
Width Across Flats: Between 0.219 inches and 0.221 inches
Head Diameter: Between 0.521 inches and 0.531 inches
