MS20008-24 Internal Wrenching Bolt

Product Series: MS
ECCN: EAR99
Schedule: 7318.15.2000

Price per Unit $27.65

Units per Pack 2

Price per Pack $55.30

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 2

Total Unit Quantity:

Total Packs 1

Total Price $55.30

Add item to quote

Material

Steel

Thread Class

3a

Fastener Length: Between 2.297 inches and 2.327 inches
Hardness Rating: 36.0 rockwell c and 40.0 rockwell c
Head Height: 0.500 inches
Internal Drive Style: Hexagon
Min. Tensile Strength (psi): 160000 pounds per square inch
Thread Diameter: 0.500 inches
Thread Direction: Right-hand
Thread Length: 0.812 inches
Thread Qty Per Inch (tpi): 20
Thread Series Designator: Unf (fine thread)
Width Across Flats: Between 0.3755 inches and 0.3785 inches
Head Diameter: Between 0.818 inches and 0.828 inches
