MS20427-4C4 Solid Rivet

Product Series: MS
ECCN: EAR99
Schedule: 7318.23.0000

Price per Unit $41.51

Units per Pack 1

Price per Pack $41.51

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: LBS

Quantity will be increased in increments of 1

Total Unit Quantity:

Total Packs 1

Total Price $41.51

Add item to quote

Head Style

Flush (flat) countersunk

Material

Steel comp 1010 or steel comp 1011 or steel comp 1012 or steel comp 1013 or steel comp 1015

Surface Treatment

Cl 3 federal specification single treatment response type 2 qq-p-416

Countersink Angle: Between 98.5 degrees and 101.5 degrees
Fastener Length: Between 0.24 inches and 0.26 inches
Head Major Diameter: Between 0.201 inches and 0.236 inches
Heat Treatment: Annealed
Material Specification: 66 federal standard all material responses
Shank Diameter: Between 0.124 inches and 0.128 inches
Shank Style: Straight
Shear Strength: 32000 single pounds per square inch
