MS20500-1032 Self-Locking Hexagon Nut (2)

MS20500-1032 Self-Locking Hexagon Nut (3)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS20500-1032 Self-Locking Hexagon Nut

Product Series: MS
ECCN: EAR99
Schedule: 7318.16.0085

Price per Unit $3.78

Units per Pack 10

Price per Pack $37.80

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:

Total Packs 1

Total Price $37.80

Add item to quote

Material

Stainless Steel

Surface Treatment

Ams 2410 assn standard single treatment response

Thread Class

3b

Thread Series

Unjf (fine thread with external controlled root radius)

Thread Size

0.190 inches

Bearing Surface Type: Washer faced
Locking Feature: Prevailing torque all metal design
Nut Height: Between 0.202 inches and 0.250 inches
Nut Style: Hexagon
Precious Material: Silver
Precious Material And Location: All surfaces silver
Tempurature Rating: 1200.0 degrees fahrenheit
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 32
Width Across Flats: Between 0.367 inches and 0.376 inches
