MS20500-624 Self-Locking Hexagon Nut

Product Series: MS
ECCN: EAR99
Schedule: 7318.16.0085

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Material

Stainless Steel

Surface Treatment

Ams2410 assn standard single treatment response

Thread Class

3b

Thread Series

Unjf (fine thread with external controlled root radius)

Thread Size

0.375 inches

Bearing Surface Finish: 125 microinches
Bearing Surface Type: Chamfered
Countersink Angle: 88.0 degrees
Locking Feature: Prevailing torque all metal design
Nut Height: Between 0.421 inches and 0.469 inches
Nut Style: Hexagon
Tempurature Rating: 1200.0 degrees fahrenheit
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 24
Width Across Flats: Between 0.553 inches and 0.564 inches
