MS20605M3W2 Blind Rivet

Product Series
MS
ECCN
EAR99
Schedule
7616.10.3000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Flush (flat) countersunk (included angle - less than 135 degrees w or w/o chamfer)
Material
Nickel alloy 400
Countersink Angle
Between 98.5 degrees and 101.5 degrees
Expansion Device
Serrated stem-type w
Fastener Length
0.203 inches
Grip Length
Between 0.063 inches and 0.125 inches
Head Major Diameter
0.179 inches
Material Specification
Qq-n-281 federal specification single material response
Shank Diameter
Between 0.093 inches and 0.097 inches
Shank Style
Pull through hollow shank
Shear Strength
70 single pounds per square inch
