MS20605MP3W3 Blind Rivet

Product Series: MS
ECCN: EAR99
Schedule: 7616.10.3000

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Head Style

Flush (flat) countersunk (included angle - less than 135 degrees w or w/o chamfer)

Material

Nickel alloy 400

Surface Treatment

Cl 3 federal specification single treatment response type 2 qq-p-416

Countersink Angle: Between 98.5 degrees and 101.5 degrees
Expansion Device: Serrated stem-type w
Fastener Length: 0.265 inches
Grip Length: Between 0.126 inches and 0.187 inches
Head Major Diameter: 0.179 inches
Material Specification: Qq-n-281 federal specification single material response
Shank Diameter: Between 0.093 inches and 0.097 inches
Shank Style: Pull through hollow shank
Shear Strength: 70 single pounds per square inch
