MS20605R3W7 Blind Rivet

Product Series
MS
ECCN
EAR99
Schedule
7616.10.3000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Flush (flat) countersunk (included angle - less than 135 degrees w or w/o chamfer)
Material
Iron alloy 660 sleeve
Surface Treatment
Qq-p-35 federal specification single treatment response
Countersink Angle
Between 98.5 degrees and 101.5 degrees
Expansion Device
Serrated stem-type w
Grip Length
Between 0.376 inches and 0.438 inches
Head Major Diameter
0.183 inches
Material Specification
Astm a493 assn standard single material response stem
Shank Diameter
Between 0.092 inches and 0.097 inches
Shank Style
Self-plugging high clinch shank
Lubrication
Dry film
