MS20605S3W5 Blind Rivet

Product Series
MS
ECCN
EAR99
Schedule
7616.10.3000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Flush (flat) countersunk (included angle - less than 135 degrees w or w/o chamfer)
Material
Steel comp 1008 sleeve or steel comp 1012 sleeve or steel comp 1018 sleeve
Surface Treatment
Cl 2 federal specification single treatment response sleeve type 2 qq-p-416
Countersink Angle
100.0 degrees
Expansion Device
Serrated stem-type w
Fastener Length
0.390 inches
Grip Length
Between 0.251 inches and 0.312 inches
Head Major Diameter
0.183 inches
Material Specification
Astm a545 assn standard single material response stem
Shank Diameter
Between 0.092 inches and 0.097 inches
Shank Style
Self-plugging high clinch shank
