MS20819-6D Flared Tube Fitting Sleeve
MS20819-6D Flared Tube Fitting Sleeve (2)
MS20819-6D Flared Tube Fitting Sleeve (3)
MS20819-6D Flared Tube Fitting Sleeve (4)
MS20819-6D Flared Tube Fitting Sleeve
MS20819-6D Flared Tube Fitting Sleeve (2)
MS20819-6D Flared Tube Fitting Sleeve (3)
MS20819-6D Flared Tube Fitting Sleeve (4)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS20819-6D Flared Tube Fitting Sleeve

Product Series
MS
ECCN
EAR99
Schedule
7307.99.4000
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Steel comp 304
Overall Length
0.500 inches
Casehardening Indicator
Not casehardened
Flange Outside Diameter
0.502 inches
Flange Width
0.172 inches
Hose/tube Outside Diameter For Which Designed
0.375 inches
Iii End Application
f161 f18 aircraft prs mgm-31 land vehicle lvt-7 tactical transport uh-1 and eh-1 (bell) utility model ch-47 boeing vertol cargo transport hel communications satellite terminal model an/tsc-54
Seat Angle In Deg
33
Sleeve Outside Diameter
0.432 inches
Specification Data
81349-mil-f-5509 government specification
Style Designator
Sleeve
