MS20913-1S Pipe Plug

Product Series: MS
ECCN: EAR99

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Material

Steel comp 1137

Thread Size

0.125 inches external

Body Core Diameter: 0.115 inches
Body Type: Cored
Connection Style: Plain
Core Depth: 0.015 inches
Drive End Style: Raised square
End Application: And m88a1 m881 recovery vehicle
Head Type: Solid
Pipe Size For Which Designed: 0.125 inches
Special Features: Countersunk 90 deg 0.075 in. max dia drill hole in plug head 0.065 in. min
Thread Direction: Right-hand external
Thread Series Designator: Anpt external
