Home » MS21042L04 Self-Locking Extended Washer Nut
MS21042L04 Self-Locking Extended Washer Nut
MS21042L04 Self-Locking Extended Washer Nut (2)
MS21042L04 Self-Locking Extended Washer Nut (3)
MS21042L04 Self-Locking Extended Washer Nut (4)
MS21042L04 Self-Locking Extended Washer Nut
MS21042L04 Self-Locking Extended Washer Nut (2)
MS21042L04 Self-Locking Extended Washer Nut (3)
MS21042L04 Self-Locking Extended Washer Nut (4)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS21042L04 Self-Locking Extended Washer Nut

Product Series
MS
ECCN
EAR99
Schedule
8112.29.0000
Price per Unit $1.26
Units per Pack 25
Price per Pack $31.50
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 25

Total Unit Quantity:
Total Packs 1
Total Price $31.50
Add item to quote
Material
Steel
Surface Treatment
Class 3 federal specification single treatment response type 2 qq-p-416
Thread Class
3b
Thread Series
Unjc
Thread Size
0.112 inches
Criticality Code Justification
Feat
Locking Feature
Prevailing torque all metal design
Nut Style
Hexagon
Overall Height
Between 0.103 inches and 0.125 inches
Special Features
The item is a flight safety critical aircraft part (fscap).
Tempurature Rating
450 degrees fahrenheit
Thread Direction
Right-hand
Thread Qty Per Inch (tpi)
40
Washer Outside Diameter
0.206 inches
Washer Thickness
0.01 inches
Width Across Flats
Between 0.15 inches and 0.158 inches
Lubrication
Dry film lubricant
