MS21042L06 Self-Locking Extended Washer Nut

Product Series: MS
ECCN: EAR99
Schedule: 8112.29.0000

Price per Unit $0.86

Units per Pack 50

Price per Pack $43.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 50

Total Unit Quantity:

Total Packs 1

Total Price $43.00

Add item to quote

Material

Steel

Surface Treatment

Class 3 federal specification single treatment response type 2 qq-p-416

Thread Class

3b

Thread Series

Unjc

Thread Size

0.138 inches

Criticality Code Justification: Feat
Hardness Rating: 49 rockwell
Locking Feature: Prevailing torque all metal design
Nut Style: Hexagon
Overall Height: Between 0.115 inches and 0.141 inches
Special Features: Nut self-locking
Tempurature Rating: 450 degrees fahrenheit
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 32
Washer Outside Diameter: 0.244 inches
Washer Thickness: 0.010 inches
Width Across Flats: Between 0.181 inches and 0.190 inches
Lubrication: Dry film lubricant
