MS21043-3 Self-Locking Extended Washer Nut
MS21043-3 Self-Locking Extended Washer Nut (2)
MS21043-3 Self-Locking Extended Washer Nut (3)
MS21043-3 Self-Locking Extended Washer Nut (4)
MS21043-3 Self-Locking Extended Washer Nut (5)
MS21043-3 Self-Locking Extended Washer Nut
MS21043-3 Self-Locking Extended Washer Nut (2)
MS21043-3 Self-Locking Extended Washer Nut (3)
MS21043-3 Self-Locking Extended Washer Nut (4)
MS21043-3 Self-Locking Extended Washer Nut (5)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS21043-3 Self-Locking Extended Washer Nut

Product Series
MS
ECCN
EAR99
Schedule
8112.29.0000
Price per Unit $1.50
Units per Pack 25
Price per Pack $37.50
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 25

Total Unit Quantity:
Total Packs 1
Total Price $37.50
Add item to quote
Material
Iron alloy
Surface Treatment
Qq-s-365 federal specification single treatment response or ams 2410 assn standard single treatment response
Thread Class
3b
Thread Series
Unf (fine thread)
Thread Size
0.190 in
Locking Feature
Prevailing torque all metal design
Material Specification
Ams5525 assn standard single material response or 5735 assn standard single material response
Nut Style
Hexagon
Overall Height
Between 0.154 inches and 0.188 inches
Precious Material
Silver
Precious Material And Location
Silver
Tempurature Rating
800 degrees fahrenheit
Thread Direction
Right-hand
Thread Qty Per Inch (tpi)
32
Washer Outside Diameter
0.330 in
Washer Thickness
0.015 in
Width Across Flats
Between 0.243 inches and 0.252 inches
