MS21044C02 Self-Locking Hexagon Nut

MS21044C02 Self-Locking Hexagon Nut (2)

MS21044C02 Self-Locking Hexagon Nut (3)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS21044C02 Self-Locking Hexagon Nut

Product Series: MS
ECCN: EAR99
Schedule: 7318.16.0085

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Material

Plastic polyhexamethylene amide locking insert

Surface Treatment

Qq-p-35 federal specification single treatment response nut

Thread Class

3b

Thread Series

Unjc

Thread Size

0.086 inches

Bearing Surface Type: Chamfered or washer faced
Countersink Angle: 88.0 degrees nut
End Application: Lav-25 slep 2320-01-123-1602
Locking Feature: Prevailing torque with nonmetallic insert
Nut Height: Between 0.133 inches and 0.153 inches
Nut Style: Hexagon
Tempurature Rating: 250.0 degrees fahrenheit
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 56
Width Across Flats: Between 0.243 inches and 0.251 inches
