MS21044N5 Self-Locking Hexagon Nut

MS21044N5 Self-Locking Hexagon Nut (2)

MS21044N5 Self-Locking Hexagon Nut (3)

MS21044N5 Self-Locking Hexagon Nut (4)

MS21044N5 Self-Locking Hexagon Nut (5)

MS21044N5 Self-Locking Hexagon Nut (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS21044N5 Self-Locking Hexagon Nut

Product Series: MS
ECCN: EAR99
Schedule: 7318.16.0085

Price per Unit $0.68

Units per Pack 50

Price per Pack $34.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 50

Total Unit Quantity:

Total Packs 1

Total Price $34.00

Add item to quote

Material

Steel

Surface Treatment

Cl 3 federal specification single treatment response except insert type 2 qq-p-416

Thread Class

3b

Thread Series

Unjf (fine thread with external controlled root radius)

Thread Size

0.312 inches

Bearing Surface Finish: 125.0 microinches
Bearing Surface Type: Chamfered or washer faced
Countersink Angle: 88.0 degrees nut
Height: Between 0.271 inches and 0.360 inches
Locking Feature: Prevailing torque with nonmetallic insert
Style: Hexagon
Tempurature Rating: 250.0 degrees fahrenheit
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 24
Width Across Flats: Between 0.492 inches and 0.502 inches
Lubrication: Soluble lubricant
