MS21083C06 Self-Locking Hexagon Nut

Product Series: MS
ECCN: EAR99
Schedule: 7318.16.0000

Price per Unit $1.99

Units per Pack 25

Price per Pack $49.75

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 25

Total Unit Quantity:

Total Packs 1

Total Price $49.75

Add item to quote

Material

Plastic polyamide locking insert

Surface Treatment

Qq-p-35 federal specification single treatment response except insert

Thread Class

3b

Thread Series

Unjc

Thread Size

0.138 inches

Bearing Surface Finish: 125.0 microinches
Bearing Surface Type: Chamfered or washer faced
Countersink Angle: 88.0 degrees nut
End Application: Mrap rg-33 auv
Locking Feature: Prevailing torque with nonmetallic insert
Nut Height: 0.141 inches
Nut Style: Hexagon
Tempurature Rating: 250.0 degrees fahrenheit
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 32
Width Across Flats: Between 0.305 inches and 0.313 inches
Lubrication: Soluble lubricant
