MS21083N3 Self-Locking Hexagon Nut

MS21083N3 Self-Locking Hexagon Nut (2)

MS21083N3 Self-Locking Hexagon Nut (3)

MS21083N3 Self-Locking Hexagon Nut (4)

MS21083N3 Self-Locking Hexagon Nut (5)

MS21083N3 Self-Locking Hexagon Nut (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS21083N3 Self-Locking Hexagon Nut

Product Series: MS
ECCN: EAR99
Schedule: 7318.16.0085

Price per Unit $0.40

Units per Pack 100

Price per Pack $40.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 100

Total Unit Quantity:

Total Packs 1

Total Price $40.00

Add item to quote

Material

Steel nut

Surface Treatment

Class 2 federal specification all treatment responses except insert type 2 qq-p-416

Thread Class

3b

Thread Series

Unjf (fine thread with external controlled root radius)

Thread Size

0.19 inches

Bearing Surface Finish: 125 microinches
Bearing Surface Type: Chamfered or washer faced
Countersink Angle: 88 degrees
Hardness Rating: 35.0 rockwell
Locking Feature: Prevailing torque with nonmetallic insert
Nut Height: 0.188 inches
Nut Style: Hexagon
Tempurature Rating: 230 degrees fahrenheit
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 32
Width Across Flats: Between 0.367 inches and 0.376 inches
Lubrication: Soluble lubricant
