MS21122-32 Loop Clamp
MS21122-32 Loop Clamp (2)
MS21122-32 Loop Clamp (3)
MS21122-32 Loop Clamp (4)
MS21122-32 Loop Clamp (5)
MS21122-32 Loop Clamp (6)
MS21122-32 Loop Clamp
MS21122-32 Loop Clamp (2)
MS21122-32 Loop Clamp (3)
MS21122-32 Loop Clamp (4)
MS21122-32 Loop Clamp (5)
MS21122-32 Loop Clamp (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS21122-32 Loop Clamp

Product Series
MS
ECCN
EAR99
Schedule
8539.29.2500
Price per Unit $35.69
Units per Pack 1
Price per Pack $35.69
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 1

Total Unit Quantity:
Total Packs 1
Total Price $35.69
Add item to quote
Material
Aluminum alloy 2024 band
Center To Center Distance Between Loop And Mounting Hole
1.499 inches
Cushioning Environmental Protection
Heat and weather resistant
Distance From Loop Center To Tongue End
Between 1.702 inches and 1.732 inches
Loop Inside Diameter
Between 1.985 inches and 2.015 inches
Material Specification
Qq-a-25015t4 federal specification single material response band
Material Thickness
Between 0.058 inches and 0.068 inches
Overall Width
0.500 inches
Style Designator
Offset mount
Tongue Hole Type
unthreaded round
Diameter
0.204 inches
