MS21299C4 Recessed Washer

Product Series: MS
ECCN: EAR99
Schedule: 7318.22.0000

Price per Unit $0.44

Units per Pack 100

Price per Pack $44.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 100

Total Unit Quantity:

Total Packs 1

Total Price $44.00

Add item to quote

Material

Steel comp 4130

Surface Treatment

Cl 2 federal specification single treatment response type 2 qq-p-416

Hardness Rating: Between 39.0 rockwell c and 45.0 rockwell c
Material Specification: Mil-s-6758 military specification single material response or mil-s-18729 military specification single material response
Material Thickness: Between 0.067 inches and 0.069 inches
Outside Diameter: Between 0.481 inches and 0.491 inches
Recess Angle: 90.0 degrees
Recess Diameter: Between 0.340 inches and 0.350 inches
Style Designator: 15 recessed
Hole Diameter: Between 0.251 inches and 0.255 inches
