MS21913J4 Threaded Tube Fitting Plug
MS21913J4 Threaded Tube Fitting Plug (2)
MS21913J4 Threaded Tube Fitting Plug (3)
MS21913J4 Threaded Tube Fitting Plug (4)
MS21913J4 Threaded Tube Fitting Plug
MS21913J4 Threaded Tube Fitting Plug (2)
MS21913J4 Threaded Tube Fitting Plug (3)
MS21913J4 Threaded Tube Fitting Plug (4)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS21913J4 Threaded Tube Fitting Plug

Product Series
MS
ECCN
EAR99
Schedule
7307.22.5000
Price per Unit $34.60
Units per Pack 2
Price per Pack $69.20
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 2

Total Unit Quantity:
Total Packs 1
Total Price $69.20
Add item to quote
Material
Steel
Overall Length
0.641 inches
Thread Class
3a external
Thread Size
0.438 inches external
Connection Style
Flareless
Head Height
0.203 inches
Material Specification
66 federal standard single material response
Maximum Operating Pressure
3000.0 pounds per square inch
Media For Which Designed
Hydrocarbon fuel/oil
Seat Angle
12.0 degrees
Specification Data
96906-ms21913 government standard
Style Designator
tube fitting flareless (note: drilled hole is optional should not be considered as a separating characteristic) plug
Thread Direction
Right-hand external
Thread Series Designator
Unjf (fine thread with external controlled root radius) external
