MS21914-3W Tube Cap

Product Series: MS
ECCN: EAR99
Schedule: 7609.00.0000

Price per Unit $30.45

Units per Pack 2

Price per Pack $60.90

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 2

Total Unit Quantity:

Total Packs 1

Total Price $60.90

Add item to quote

Material

Aluminum alloy 2024

Surface Treatment

Type 2 military specification single treatment response mil-a-8625

Thread Class

3b internal

Thread Size

0.375 inches internal

Connection Style: Pressure seal flared
Iii End Application: Aircraft fluid systems; mrap buffalo mk2a2
Material Specification: Qq-a-225/6 federal specification single material response
Seat Angle: 45.0 degrees
Specification Data: 96906-ms21914 government standard
Style Designator: Flared tube cap
Thread Direction: Right-hand internal
Thread Series Designator: Unjf (fine thread with external controlled root radius) internal
Tube Outside Diameter For Which Designed: 0.188 inches
