MS21919WCG3 Loop Clamp
MS21919WCG3 Loop Clamp (2)
MS21919WCG3 Loop Clamp (3)
MS21919WCG3 Loop Clamp (4)
MS21919WCG3 Loop Clamp (5)
MS21919WCG3 Loop Clamp (6)
MS21919WCG3 Loop Clamp
MS21919WCG3 Loop Clamp (2)
MS21919WCG3 Loop Clamp (3)
MS21919WCG3 Loop Clamp (4)
MS21919WCG3 Loop Clamp (5)
MS21919WCG3 Loop Clamp (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS21919WCG3 Loop Clamp

Product Series
MS
ECCN
EAR99
Schedule
7616.10.9090
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Rubber chloroprene class cr cushion
Surface Treatment
Qq-p-35 federal specification single treatment response band
Center To Center Distance Between Loop And Mounting Hole
Between 0.483 inches and 0.513 inches
Distance From Loop Center To Tongue End
0.686 inches
Loop Inside Diameter
Between 0.173 inches and 0.203 inches
Material Specification
Mil-s-5059 military specification 1st material response band or ams 5510 assn standard 2nd material response band
Material Thickness
0.032 inches
Overall Width
Between 0.365 inches and 0.385 inches
Style Designator
Offset mount
Tongue Hole Type
unthreaded round
Diameter
Between 0.199 inches and 0.209 inches
