MS21919WCH26 Loop Clamp
MS21919WCH26 Loop Clamp (2)
MS21919WCH26 Loop Clamp (3)
MS21919WCH26 Loop Clamp (4)
MS21919WCH26 Loop Clamp
MS21919WCH26 Loop Clamp (2)
MS21919WCH26 Loop Clamp (3)
MS21919WCH26 Loop Clamp (4)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS21919WCH26 Loop Clamp

NSN
5340-01-168-9785
Product Series
MS
ECCN
EAR99
Schedule
8539.29.2500
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Steel band
Surface Treatment
Qq-p-35 federal specification single treatment response band
Center To Center Distance Between Loop And Mounting Hole
Between 1.265 inches and 1.295 inches
Cushioning Environmental Protection
Corrosion resistant and weather resistant and oil resistant
Distance From Loop Center To Tongue End
1.498 inches
Loop Inside Diameter
Between 1.610 inches and 1.640 inches
Material Specification
Ams 3303 assn standard single material response cushion
Material Thickness
0.032 inches
Overall Width
Between 0.490 inches and 0.510 inches
Style Designator
Offset mount
Tongue Hole Type
unthreaded round
Diameter
Between 0.199 inches and 0.209 inches
