MS21919WCJ2 Loop Clamp
MS21919WCJ2 Loop Clamp (2)
MS21919WCJ2 Loop Clamp (3)
MS21919WCJ2 Loop Clamp (4)
MS21919WCJ2 Loop Clamp (5)
MS21919WCJ2 Loop Clamp (6)
MS21919WCJ2 Loop Clamp
MS21919WCJ2 Loop Clamp (2)
MS21919WCJ2 Loop Clamp (3)
MS21919WCJ2 Loop Clamp (4)
MS21919WCJ2 Loop Clamp (5)
MS21919WCJ2 Loop Clamp (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS21919WCJ2 Loop Clamp

Product Series
MS
ECCN
EAR99
Schedule
8539.29.2500
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Rubber fluorosilicone class fq cushion
Surface Treatment
Qq-p-35 federal specification single treatment response band
Center To Center Distance Between Loop And Mounting Hole
Between 0.442 inches and 0.472 inches
Cushioning Environmental Protection
Oil resistant and fuel resistant
Distance From Loop Center To Tongue End
0.675 inches
Loop Inside Diameter
Between 0.110 inches and 0.140 inches
Material Specification
Gr60 military specification single material response cushion cl1 ty2 mil-r-25988
Material Thickness
0.032 inches
Overall Width
Between 0.365 inches and 0.385 inches
Special Features
Cushion color blue
Style Designator
Offset mount
Tongue Hole Type
unthreaded round
Diameter
Between 0.199 inches and 0.209 inches
