MS21919WCJ9 Loop Clamp

Product Series
MS
ECCN
EAR99
Schedule
8539.29.2500
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Rubber fluorosilicone class fq cushion or rubber fluorocarbon class fpm cushion
Surface Treatment
Qq-p-35 federal specification single treatment response band
Center To Center Distance Between Loop And Mounting Hole
Between 0.734 inches and 0.764 inches
Cushioning Environmental Protection
aromatic and hydraulic fluid and oil resistant fuel
Distance From Loop Center To Tongue End
Between 0.952 inches and 0.982 inches
Loop Inside Diameter
Between 0.548 inches and 0.578 inches
Material Specification
Mil-s-6721 military specification all material responses band
Material Thickness
Between 0.029 inches and 0.036 inches
Overall Width
Between 0.485 inches and 0.515 inches
Style Designator
Offset mount
Tongue Hole Type
unthreaded round
Diameter
0.204 inches
