MS21919WDG22 Loop Clamp

Product Series
MS
ECCN
EAR99
Schedule
8539.29.2500
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Rubber chloroprene class cr cushion
Surface Treatment
Mil-c-5541 military specification single treatment response band
Center To Center Distance Between Loop And Mounting Hole
Between 1.172 inches and 1.202 inches
Cushioning Environmental Protection
Weather resistant
Distance From Loop Center To Tongue End
1.405 inches
Loop Inside Diameter
Between 1.360 inches and 1.390 inches
Material Specification
Ams 3209 assn standard single material response cushion
Material Thickness
0.062 inches
Overall Width
Between 0.490 inches and 0.510 inches
Specification Data
26512-gs14 manufacturers specification
Style Designator
Offset mount
Tongue Hole Type
unthreaded round
Diameter
0.204 inches
