MS24621-7 Machine Screw

Product Series: MS
ECCN: EAR99
Schedule: 7318.15.2091

Price per Unit $4.08

Units per Pack 10

Price per Pack $40.80

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:

Total Packs 1

Total Price $40.80

Add item to quote

Head Style

Pan

Material

Steel comp 1016 or steel comp 1018 or steel comp 1019 or steel comp 1021 or steel comp 1022 or steel comp 1524

Surface Treatment

Qq-p-416 type 2 cl 3 federal specification all treatment responses

Fastener Length: Between 0.157 inches and 0.188 inches
Features: Casehardened
Features Provided: Casehardened
Head Height: Between 0.070 inches and 0.080 inches
Internal Drive Style: Cross recess type 1
Material Specification: Aisi assn standard all material responses
Nonmachine Thread Diameter: 0.112 inches
Nonmachine Thread Style: Dog type (type b or c)
Head Diameter: Between 0.205 inches and 0.219 inches
