MS24665-361 Cotter Pin

Product Series
MS
ECCN
EAR99
Schedule
7318.24.0000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Steel comp 1008 or steel comp 1010 or steel comp 1012 or steel comp 1015 or steel comp 1017 or steel comp 1018 or steel comp 1020
Surface Treatment
Cl 3 federal specification single treatment response type 2 qq-p-416
Material Specification
66 federal standard all material responses
Point Type
Extended prong square cut
Style Designator
Standard
Underloop Length
Between 2.125 inches and 2.375 inches
Diameter
Between 0.116 inches and 0.120 inches
