MS24665-366 Cotter Pin

Product Series: MS
ECCN: EAR99
Schedule: 7318.24.0000

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Material

Steel comp 302 or steel comp 304

Surface Treatment

Astm a380 assn standard single treatment response

Departure From Cited Designator: As modified by point style and packing data
Hardness Rating: 55.0 rockwell superficial 15-n and 67.0 rockwell superficial 15-n
Material Specification: Astm a493 assn standard all material responses
Point Type: Extended prong mitre end
Style Designator: Standard
Underloop Length: Between 0.438 inches and 0.625 inches
Diameter: Between 0.116 inches and 0.120 inches
