MS24665-88 Cotter Pin

Product Series: MS
ECCN: EAR99
Schedule: 7318.24.0000

Price per Unit $0.35

Units per Pack 100

Price per Pack $35.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 100

Total Unit Quantity:

Total Packs 1

Total Price $35.00

Add item to quote

Material

Steel comp 302 or steel comp 304

Surface Treatment

Qq-p-35 federal specification single treatment response

Hardness Rating: 65.0 rockwell superficial 15-n and 78.0 rockwell superficial 15-n
Material Specification: 66 federal standard all material responses
Nondefinitive Specification/std Data: C type
Point Type: Extended prong square cut
Style Designator: Standard
Underloop Length: Between 0.720 inches and 0.780 inches
Diameter: 0.047 inches
