MS27039-4-10 Machine Screw
MS27039-4-10 Machine Screw (2)
MS27039-4-10 Machine Screw (3)
MS27039-4-10 Machine Screw
MS27039-4-10 Machine Screw (2)
MS27039-4-10 Machine Screw (3)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS27039-4-10 Machine Screw

Product Series
MS
ECCN
EAR99
Schedule
7318.15.9000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Pan
Material
Steel
Surface Treatment
Qq-p-416 type 2 cl 3 federal specification single treatment response
Thread Class
3a
Fastener Length
Between 0.641 inches and 0.688 inches
Hardness Rating
Between 26.0 rockwell c and 32.0 rockwell c
Head Height
Between 0.162 inches and 0.175 inches
Internal Drive Style
Cross recess type 1
Material Specification
Mil-s-6050 military specification 1st material response or ams 6300 assn standard 2nd material response
Min. Tensile Strength (psi)
125000 pounds per square inch
Thread Diameter
0.250 inches
Thread Direction
Right-hand
Thread Length
Between 0.430 inches and 0.578 inches
Thread Qty Per Inch (tpi)
28
Thread Series Designator
Unf (fine thread)
Head Diameter
Between 0.473 inches and 0.492 inches
