MS27183-16 Flat Washer

Product Series: MS
ECCN: EAR99
Schedule: 7318.22.0000

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Material

Steel

Surface Treatment

Cl 3 federal specification single treatment response type 2 qq-p-416

Center Hole Shape: Round
Cross Sectional Shape: Rectangular
Edge Shape: Round
End Application: Mrap buffalo mk2a2
Material Specification: 66 federal standard single material response
Nondefinitive Specification/std Data: A type and 1 grade and a class
Overall Diameter: Between 0.915 inches and 0.937 inches
Thickness: Between 0.051 inches and 0.080 inches
Hole Diameter: Between 0.464 inches and 0.484 inches
