MS3498-2 Nut Assembly

Product Series: MS
ECCN: EAR99
Schedule: 7318.16.0000

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Material

Aluminum alloy 2011

Surface Treatment

Mil-a-8625 military specification single treatment response

Thread Class

1b

Thread Series

Unef (extra fine thread)

Thread Size

0.250 inches

Nut Diameter: Between 0.365 inches and 0.375 inches
Nut Height: Between 0.187 inches and 0.192 inches
Nut Style: Spline
Pilot Diameter: Between 0.314 inches and 0.317 inches
Pilot Length: 0.157 inches
Thread Direction: Left-hand
Thread Qty Per Inch (tpi): 32
