MS35308-305 Hexagon Head Cap Screw

MS35308-305 Hexagon Head Cap Screw (2)

MS35308-305 Hexagon Head Cap Screw (3)

MS35308-305 Hexagon Head Cap Screw (4)

MS35308-305 Hexagon Head Cap Screw (5)

MS35308-305 Hexagon Head Cap Screw (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS35308-305 Hexagon Head Cap Screw

Product Series: MS
ECCN: EAR99
Schedule: 7318.15.2091

Price per Unit $1.36

Units per Pack 25

Price per Pack $34.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 25

Total Unit Quantity:

Total Packs 1

Total Price $34.00

Add item to quote

Head Style

Hexagon

Material

Steel

Surface Treatment

Qq-p-35 federal specification single treatment response

Thread Class

2a

Fastener Length: 0.625 inches
Head Height: Between 0.150 inches and 0.163 inches
Material Specification: 66 federal standard all material responses
Min. Tensile Strength (psi): 80000 pounds per square inch
Thread Diameter: 0.250 inches
Thread Direction: Right-hand
Thread Length: 0.625 inches
Thread Qty Per Inch (tpi): 28
Thread Series Designator: Unf (fine thread)
Width Between Flats: Between 0.428 inches and 0.438 inches
