MS35335-61 Lock Washer

Product Series: MS
ECCN: EAR99
Schedule: 7318.21.0000

Price per Unit $0.33

Units per Pack 100

Price per Pack $33.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 100

Total Unit Quantity:

Total Packs 1

Total Price $33.00

Add item to quote

Material

Steel comp 410

Surface Treatment

Qq-p-35 federal specification single treatment response

Hardness Rating: Between 40.0 rockwell c and 50.0 rockwell c
Iii End Application: Mrap - cougar
Material Specification: 66 federal standard single material response
Material Thickness: Between 0.023 inches and 0.028 inches
Nondefinitive Specification/std Data: B type
Outside Diameter: Between 0.494 inches and 0.510 inches
Style Designator: Flat external teeth
Hole Diameter: Between 0.256 inches and 0.267 inches
