MS35338-47 Lock Washer

MS35338-47 Lock Washer (2)

MS35338-47 Lock Washer (3)

MS35338-47 Lock Washer (4)

MS35338-47 Lock Washer (5)

MS35338-47 Lock Washer (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS35338-47 Lock Washer

Product Series: MS
ECCN: EAR99
Schedule: 7318.21.0000

Price per Unit $0.27

Units per Pack 100

Price per Pack $27.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 100

Total Unit Quantity:

Total Packs 1

Total Price $27.00

Add item to quote

Material

Steel comp 1060 or steel comp 1561 or steel comp 1064 or steel comp 1065 or steel comp 1566 or steel comp 1069 or steel comp 1070 or steel comp 1572 or steel comp 1074 or steel comp 1075 or steel comp 1080

Surface Treatment

Cl 3 federal specification single treatment response type 2 qq-p-416

Criticality Code Justification: Feat
End Application: Mrap buffalo mk2a2
Hardness Rating: Between 45.0 rockwell c and 53.0 rockwell c
Material Specification: 66 federal standard all material responses
Material Thickness: Between 0.109 inches and 0.119 inches
Outside Diameter: 0.779 inches
Special Features: Weapon system essential
Style Designator: Split helical-right hand
Hole Diameter: Between 0.446 inches and 0.459 inches
