MS35650-3254 Plain Hexagon Nut

NSN: 5310-00-400-5503
Product Series: MS
ECCN: EAR99
Schedule: 7318.16.0085

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote

Material

Steel

Surface Treatment

Qq-p-35 federal specification single treatment response

Thread Class

Thread Series

Unf (fine thread)

Thread Size

0.250 inches

Bearing Surface Type: Flat or chamfered
Departure From Cited Designator: As modified by material
End Application: Mrap rg-33
Material Specification: Comp 300 series federal standard all material responses 66
Nondefinitive Specification/std Data: 2 type and 13 style
Nut Height: Between 0.178 inches and 0.193 inches
Nut Style: Hexagon
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 28
Width Across Flats: Between 0.423 inches and 0.437 inches
