MS51047-38 Machine Screw

Product Series
MS
ECCN
EAR99
Schedule
7318.15.2091
Price per Unit $4.85
Units per Pack 10
Price per Pack $48.50
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:
Total Packs 1
Total Price $48.50
Add item to quote
Head Style
Headless (setscrew)
Material
Steel comp 302 or steel comp 303 or steel comp 304 or steel comp 316
Surface Treatment
Qq-p-35 federal specification single treatment response
Thread Class
3a
Fastener Length
Between 0.490 inches and 0.510 inches
Internal Drive Style
Hexagon
Material Specification
66 federal standard all material responses
Nondefinitive Specification/std Data
1 type and 6 style
Point Style
Half dog
Thread Diameter
0.190 inches
Thread Direction
Right-hand
Thread Length
Between 0.441 inches and 0.469 inches
Thread Qty Per Inch (tpi)
32
Thread Series Designator
Unf (fine thread)
Width Across Flats
0.094 inches
