MS51830CA201L Screw Thread Insert

Product Series
MS
ECCN
EAR99
Schedule
7318.16.0085
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Surface Treatment
Qq-p-35 federal specification single treatment response
Thread Class
3b
Thread Size
0.19 in
Features
Individually keyed
Features Provided
Individually keyed
Full Internal Thread Length
0.242 in
Insert Size
0.313-18 unc (coarse thread) 2a
Internal Thread Relief Depth
0.07 in
Length
0.312 in
Style Designator
Grooved keylock
Thread Qty Per Inch (tpi)
32
Thread Series Designator
Unjf (fine thread with external controlled root radius)
