MS51831-108 Screw Thread Insert

Product Series
MS
ECCN
EAR99
Schedule
7318.16.0085
Price per Unit $13.12
Units per Pack 5
Price per Pack $65.60
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 5

Total Unit Quantity:
Total Packs 1
Total Price $65.60
Add item to quote
Material
Steel comp 302
Surface Treatment
Qq-p-35 federal specification single treatment response
Thread Class
3b
Thread Size
0.625 inches
Full Internal Thread Length
0.775 inches
Insert Size
Class 2a 7/8 in.-14 unf (fine thread)
Internal Thread Relief Depth
0.100 inches
Length
0.875 inches
Material Specification
Fed standard 66 federal standard single material response
Style Designator
Keylock
Thread Direction
Right-hand
Thread Length
0.775 inches
Thread Qty Per Inch (tpi)
11
Thread Series Designator
Unjc
