Home » MS51848-8 Lock Washer
MS51848-8 Lock Washer
MS51848-8 Lock Washer (2)
MS51848-8 Lock Washer (3)
MS51848-8 Lock Washer (4)
MS51848-8 Lock Washer (5)
MS51848-8 Lock Washer (6)
MS51848-8 Lock Washer
MS51848-8 Lock Washer (2)
MS51848-8 Lock Washer (3)
MS51848-8 Lock Washer (4)
MS51848-8 Lock Washer (5)
MS51848-8 Lock Washer (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS51848-8 Lock Washer

Product Series
MS
ECCN
EAR99
Schedule
7318.21.0000
Price per Unit $0.22
Units per Pack 100
Price per Pack $22.00
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 100

Total Unit Quantity:
Total Packs 1
Total Price $22.00
Add item to quote
Material
Steel comp 1060 or steel comp 1561 or steel comp 1064 or steel comp 1065 or steel comp 1070 or steel comp 1074 or steel comp 1075 or steel comp 1080
Surface Treatment
Cl 2 federal specification single treatment response type 2 qq-p-416
Hardness Rating
Between 43.0 rockwell c and 53.0 rockwell c
Material Specification
66 federal standard all material responses
Material Thickness
0.047 inches
Outside Diameter
0.267 inches
Style Designator
Split helical-right hand
Hole Diameter
Between 0.167 inches and 0.174 inches
