MS51861-35 Tapping Screw

Product Series: MS
ECCN: EAR99
Schedule: 7318.15.9000

Price per Unit $0.34

Units per Pack 100

Price per Pack $34.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 100

Total Unit Quantity:

Total Packs 1

Total Price $34.00

Add item to quote

Head Style

Pan

Material

Steel

Surface Treatment

Class 3 federal specification single treatment response type 2 qq-p-416

Fastener Length: Between 0.469 inches and 0.531 inches
Features: Casehardened
Features Provided: Casehardened
Head Height: Between 0.105 inches and 0.115 inches
Internal Drive Style: Cross recess type 1
Nondefinitive Specification/std Data: Ab type
Nonmachine Thread Diameter: 0.164 inches
Nonmachine Thread Style: Ab or ba gimlet point
Head Diameter: Between 0.306 inches and 0.322 inches
