MS51957-41B Screw
- Product Series
- MS
- ECCN
- EAR99
- Schedule
- 7318.15.2091
Unit of Measure:
EA
Add to Quote
We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.
Add to QuoteCouldn't load pickup availability
- Fastener Length
- Between 0.219 inches and 0.250 inches
- Head Height
- Between 0.105 inches and 0.115 inches
- Internal Drive Style
- Cross recess type 1
- Min. Tensile Strength (psi)
- 80000 pounds per square inch
- Nondefinitive Specification/std Data
- 3 type and 9c style
- Screw Material
- Stainless steel or steel
- Screw Material Specification
- 300 series federal standard 1st material response or comp 16-18 or 18-8 assn standard 2nd material response 300 series federal specification 1st material response or 66 qq-s-763
- Screw Surface Treatment
- Oxide
- Screw Surface Treatment Specification
- Cl 4 military specification single treatment response mil-c-13924
- Thread Diameter
- 0.164 inches
- Thread Direction
- Right-hand
- Thread Length
- Between 0.157 inches and 0.250 inches
- Thread Qty Per Inch (tpi)
- 32
- Thread Series Designator
- Unc (coarse thread)
- Head Diameter
- Between 0.306 inches and 0.322 inches
