MS51957-64 Machine Screw
MS51957-64 Machine Screw (2)
MS51957-64 Machine Screw (3)
MS51957-64 Machine Screw (4)
MS51957-64 Machine Screw (5)
MS51957-64 Machine Screw (6)
MS51957-64 Machine Screw
MS51957-64 Machine Screw (2)
MS51957-64 Machine Screw (3)
MS51957-64 Machine Screw (4)
MS51957-64 Machine Screw (5)
MS51957-64 Machine Screw (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS51957-64 Machine Screw

Product Series
MS
ECCN
EAR99
Schedule
7318.15.2091
Price per Unit $0.45
Units per Pack 100
Price per Pack $45.00
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 100

Total Unit Quantity:
Total Packs 1
Total Price $45.00
Add item to quote
Head Style
Pan
Material
Steel
Surface Treatment
Mil-c-13924 cl 4 military specification single treatment response
Thread Class
2a
Fastener Length
Between 0.594 inches and 0.625 inches
Head Height
Between 0.122 inches and 0.133 inches
Internal Drive Style
Cross recess type 1
Min. Tensile Strength (psi)
80000 pounds per square inch
Nondefinitive Specification/std Data
3 type and 9c style
Thread Diameter
0.190 inches
Thread Direction
Right-hand
Thread Length
Between 0.511 inches and 0.625 inches
Thread Qty Per Inch (tpi)
24
Thread Series Designator
Unc (coarse thread)
Head Diameter
Between 0.357 inches and 0.373 inches
