MS9024-04 Loop Clamp
MS9024-04 Loop Clamp (2)
MS9024-04 Loop Clamp (3)
MS9024-04 Loop Clamp (4)
MS9024-04 Loop Clamp (5)
MS9024-04 Loop Clamp (6)
MS9024-04 Loop Clamp
MS9024-04 Loop Clamp (2)
MS9024-04 Loop Clamp (3)
MS9024-04 Loop Clamp (4)
MS9024-04 Loop Clamp (5)
MS9024-04 Loop Clamp (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

MS9024-04 Loop Clamp

Product Series
MS
ECCN
EAR99
Schedule
8539.29.2500
Price per Unit $6.24
Units per Pack 10
Price per Pack $62.40
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:
Total Packs 1
Total Price $62.40
Add item to quote
Material
Steel comp 4130 band
Center To Center Distance Between Loop And Mounting Hole
Between 0.555 inches and 0.565 inches
Distance From Loop Center To Tongue End
Between 0.773 inches and 0.783 inches
Loop Inside Diameter
0.438 inches
Material Specification
Ams 6350 assn standard single material response band
Material Thickness
Between 0.025 inches and 0.037 inches
Overall Width
Between 0.484 inches and 0.516 inches
Style Designator
Offset mount
Tongue Hole Type
unthreaded round
Diameter
Between 0.199 inches and 0.209 inches
